| Working Pressure | UNI 9561-2, DIN 8076, ISO 14236, BRL-K03 |
| Polyethylene (PE) Pipes | UNI 7611, UNI 7990, DIN 9072, DIN 8074, UNI 10910, EN 12201 |
| Threads | ISO 7, ANSIASME B1-20 |
| Flanges | ISO 2084, DIN 2501, UN 17442 |
| Code | F (BSP) | H (MM) | L (MM) | D (MM) | PN |
|---|---|---|---|---|---|
| 2302020 | G 1/2 | 19 | 43 | 32 | 10 |
| 2302030 | G 3/4 | 23 | 51 | 40 | 10 |
| 2302040 | G 1 | 23 | 51 | 45 | 10 |
| 2302050 | G 1 1/4 | 25 | 55 | 56 | 10 |
| 2302060 | G 1 1/2 | 25 | 55 | 62 | 6 |
| 2302070 | G 2 | 28 | 61 | 76 | 6 |
